PowAirBox II A - 230 V (Supply Unit Kit)

The PowAirBox II is a system for supplying power and compressed air to emergency vehicles with automatic ejection.

Highlights

  • Low installation depth (75 mm instead of 121 mm)
  • Sensor monitoring with start prevention
  • Wear-free automatic and manual ejection
  • Integrated undervoltage detector
  • Wear-free due to intelligent power electronics

Details

  • Compressed air: Yes
  • Nominal voltage (suppy unit): 230 V
  • Product number: 1101002003
Choose other variant
Request price

Product description

The PowAirBox II, like its predecessor model, is a system for supplying power and compressed air to emergency vehicles with automatic ejection.
The supply is effected via a special coupling in which compressed air and power are combined in one line. The robust housing is made of glass-fibre reinforced polyamide and has IP55 protection, making it dust-proof and splash-proof. Via indication integrated in the front of the PowAirBox II, the status of the feeding mains as well as the charging status of the batteries can be read easily and at any time. The integrated undervoltage detector alerts visually and acoustically in the event of a deep discharge of the vehicle battery.
The disconnection between the power and compressed air supply and the automatic ejection of the coupling is monitored and controlled by a newly developed sensor technology and also works when operated manually via a touch sensor. As long as the coupling is not ejected, the start prevention is activated to provide maximum safety.
A superior multi-stage power control monitors the insertion and disconnection of the coupling and controls the connection and disconnection of the load. This optimises wear-free connection and disconnection even with particularly powerful inductive and capacitive loads.

Upgrade made easy thanks to total compatibility

The PowAirBox II is fully compatible with the previous version. Both the fit of the coupling and the mounting dimensions are unchanged, so vehicles can be easily upgraded to the PowAirBox II. A corresponding adapter makes the conversion uncomplicated. The low installation depth makes installation simple and flexible.

Technical Information

Compressed air
Yes
Nominal voltage (suppy unit)
230 V
Air pressure
13 bar
Colour
Black
Contacts
L1/PE/N + 2x HK
Current (AC), max.
16 A
Installation depth
75 mm
International Protection (IP class)
IP55
Material
Polyamide
Nominal voltage (battery)
12 V/24 V
Protection class
II
Status display
LED
Dimensions (L x W x H)
192 x 109 x 100.5 mm
Weight
1.2 kg

3D View

Variants

Reset all filters
  • PowAirBox II A - 230 V (Supply Unit Kit)

    1101002003

    Compressed air
    Yes
    Nominal voltage (suppy unit)
    230 V
    Current variant
  • PowAirBox II B - 230 V (Supply Unit Kit)

    1101002005

    Nominal voltage (suppy unit)
    230 V
    Compressed air
    No
